Epson TM-S1000 (031): USB, PS, EDG, Frank stamp, 60DPM, CD

CHEQUE SCANNER W/ Frank stamp, W/ AC, 60DPM, CD; USB; Epson Cool White (ECW); Power Supply

High reliability cheque and coupon scanner

Epson’s TM-S1000 cheque scanner is ideal for banks and corporations that want to capture cheques using back office capture (BOC), remote deposit capture (RDC) or a combination of the two. The Epson cheque scanner comes in both a 30 DPM and 60 DPM version and features RDMs MICR algorithms and imaging to provide one of the highest MICR accuracy of any desktop scanner on the market today. The TM-S1000 also features clear electronic endorsements, a double cheque detector that virtually eliminates double cheque feeding and a built-in franker that prints a static message on cheques to prevent double processing.

Flexibility to meet application requirements

The TM-S1000 comes with two pocket support as a standard feature. This gives you the flexibility to process and segregate different types of documents such as cheques and payment coupons. In addition, the 100 sheet document feeder allows high volume processing.

Easy to use and control

Whether you use TM-S1000 in the back office or at a busy teller station, the S1000 has been designed for easy maintenance. The cheque scanning process is simple and replacing the franker unit is quick and easy with no special training required. The Scanner also features advanced self-diagnostics which keep the operator informed of the scanner status and clear error messages.

Epson quality and reliability

With a MCBF of 2.47 million documents, the TM-S1000 has the reliability you need. As a world leading manufacturer of retail and office equipment, Epson offers high quality engineering with world class quality control and support.

BS-MICR
BS-Remote Maintenance

Download additional information

Epson TM-S1000 (031): USB, PS, EDG, Frank stamp, 60DPM, CD Datasheet / Brochure
Epson TM-S1000 (031): USB, PS, EDG, Frank stamp, 60DPM, CD

Tech Specs

Product features and specifications are subject to change without prior notice.

SKU: A41A266031
  • Image Scanner Unit

    Scanning mode
    256-level greyscale, Black and White
    Data format
    Grey scale: TIFF, JPEG, BMP, Raster, Black and White: TIFF, BMP
    Supported document type
    Normal paper
    Document size
    120 mm - 235 mm (L) x 68 mm - 120 mm (H)
    Pocket capacities
    ASF: 100 Sheets, Main pocket: 100 Sheets, Sub pocket: 50 Sheets
    Pockets
    Multi feed pocket, Two output pockets
    MICR reader
    Permanent magnetic bias
    MICR symbologies
    E13B, CMC7
    OCR
    E13B, OCR A, OCR B
  • Cut Sheet Paper Unit

    Endorsement Print
    Yes
    Life franking cartridge
    Exclusive franking cartridge EFC-01
  • Reliability - Recept printer unit

    Life franking cartridge
    18,000 Sheets
    Reliability
    Life: 1,000,000 Sheets / MCBF: 2,470,000 cycles
  • General

    Colour
    Epson Dark Grey
    Interfaces
    USB 2.0
    Product dimensions
    355‎ x 160 x 176 mm (Width x Depth x Height)
    Product weight
    4 kg
    What's in the box
    Driver and utilities (CD), Main unit, PS-180, Power switch cover, USB cable, User manual
    Supported Humidity
    Operation 20% - 80%, Storage 5% - 85%
    Supported Temperature
    Operation 10° C - 40° C, Storage -20° C - 60° C
